Maserati Nettuno Engine

The new “Made in Modena” engine, a traditional 90° V6, has been taken to unheard of power and torque levels and will be used for the first time on the MC20 super sportscar. It delivers 630CV at 7500rpm and 730 Nm of torque from 3000rpm with a specific power output of 210CV/litre.
Turbochargers: Twin Side Turbo with electronic actuated Waste Gate
The soul of the engine is the innovative pre-chamber combustion system featuring twin-spark plugs. This technology is derived from Formula 1 and is now available, for the first time, on an engine destined for the road.

PDI (Direct Injection 350bar + Port Injection 6bar)


Twin Spark with passive pre-chamber

Twin injection system – direct and indirect: linked to the fuel supply pressure at 350bar, the system reduces noise low down on the rev range, lowering emissions and improving consumption.
The pre-chamber: a combustion chamber is set between the central electrode and the traditional combustion chamber and connected by a series of specially-designed holes.
Lateral sparkplug: a traditional sparkplug acts as a support to ensure constant combustion when the engine is operating at a level that doesn’t need the pre-chamber to kick in.
